硬盘监控和分析工具：Smartctl

共计 6346 个字符，预计需要花费 16 分钟才能阅读完成。

Smartctl（S.M.A.R.T 自监控，分析和报告技术）是类 Unix 系统下实施 SMART 任务命令行套件或工具，它用于打印 SMART自检 和错误日志 ，启用并禁用 SMRAT 自动检测，以及初始化设备自检。

Smartctl 对于 Linux 物理服务器十分有用，在这些服务器上，可以对智能磁盘进行错误检查，并将与 硬件 RAID相关的磁盘信息摘录下来。

在本帖中，我们将讨论 smartctl 命令的一些实用样例。如果你的 Linux 上海没有安装 smartctl，请按以下步骤来安装。

使用 Smartctl 查 Dell 服务器坏道实录  http://www.linuxidc.com/Linux/2012-07/65723.htm

安装 Smartctl

对于 Ubuntu

1. $ sudo apt–get install smartmontools

对于 CentOS & RHEL

1. # yum install smartmontools

启动 Smartctl 服务

对于 Ubuntu

1. $ sudo /etc/init.d/smartmontools start

对于 CentOS & RHEL

1. # service smartd start ; chkconfig smartd on

样例

样例：1 检查磁盘的 Smart 功能是否启用

1. root@linuxtechi:~# smartctl –i /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF INFORMATION SECTION ===
6. ModelFamily:SeagateMomentus5400.6
7. DeviceModel: ST9320325AS
8. SerialNumber:5VD2V59T
9. LU WWN DeviceId:5000c50020a37ec4
10. FirmwareVersion:0002BSM1
11. UserCapacity:320,072,933,376 bytes [320 GB]
12. SectorSize:512 bytes logical/physical
13. RotationRate:5400 rpm
14. Deviceis:In smartctl database [for details use:–P show]
15. ATA Versionis: ATA8–ACS T13/1699–D revision 4
16. SATA Versionis: SATA 2.6,1.5Gb/s
17. LocalTimeis:SunNov1612:32:092014 IST
18. SMART support is:Available– device has SMART capability.
19. SMART support is:Enabled

这里‘/dev/sdb’是你的硬盘。上面输出中的最后两行显示了 SMART 功能已启用。

样例：2 启用磁盘的 Smart 功能

1. root@linuxtechi:~# smartctl –s on /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF ENABLE/DISABLE COMMANDS SECTION ===
6. SMART Enabled.

样例：3 禁用磁盘的 Smart 功能

1. root@linuxtechi:~# smartctl –s off /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF ENABLE/DISABLE COMMANDS SECTION ===
6. SMART Disabled.Use option –s with argument ‘on’ to enable it.

样例：4 显示磁盘的详细 Smart 信息

1. root@linuxtechi:~# smartctl –a /dev/sdb // For IDE drive
2. root@linuxtechi:~# smartctl –a –d ata /dev/sdb // For SATA drive

样例：5 显示磁盘总体健康状况

1. root@linuxtechi:~# smartctl –H /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF READ SMART DATA SECTION ===
6. SMART overall–health self–assessment test result: PASSED
7. Warning:This result is based on an Attribute check.
8. Please note the following marginal Attributes:
9. ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
10. 190Airflow_Temperature_Cel0x0022067045045Old_ageAlwaysIn_the_past33(Min/Max25/33)

样例：6 使用 long 和 short 选项测试硬盘

Long 测试

1. root@linuxtechi:~# smartctl —test=long/dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF OFFLINE IMMEDIATE AND SELF–TEST SECTION ===
6. Sending command:“Execute SMART Extended self-test routine immediately in off-line mode”.
7. Drive command “Execute SMART Extended self-test routine immediately in off-line mode” successful.
8. Testing has begun.
9. Please wait 102 minutes for test to complete.
10. Test will complete after SunNov1614:29:432014
11.
12. Use smartctl –X to abort test.

或者，我们可以重定向测试输出到日志文件，就像下面这样

1. root@linuxtechi:~# smartctl —test=long/dev/sdb >/var/log/long.text

Short 测试

1. root@linuxtechi:~# smartctl —test=short/dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF OFFLINE IMMEDIATE AND SELF–TEST SECTION ===
6. Sending command:“Execute SMART Short self-test routine immediately in off-line mode”.
7. Drive command “Execute SMART Short self-test routine immediately in off-line mode” successful.
8. Testing has begun.
9. Please wait 1 minutes for test to complete.
10. Test will complete after SunNov1612:51:452014
11.
12. Use smartctl –X to abort test.

或

1. root@linuxtechi:~# smartctl —test=short/dev/sdb >/var/log/short.text

注意：short 测试将花费最多 2 分钟，而在 long 测试中没有时间限制，因为它会读取并验证磁盘的每个段。

样例：7 查看驱动器的自检结果

1. root@linuxtechi:~# smartctl –l selftest /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF READ SMART DATA SECTION ===
6. SMART Self–test log structure revision number 1
7. NumTest_DescriptionStatusRemainingLifeTime(hours) LBA_of_first_error
8. # 1 Short offline Completed: read failure 90% 492 210841222
9. # 2 Extended offline Completed: read failure 90% 492 210841222

样例：8 计算测试时间估值

1. root@linuxtechi:~# smartctl –c /dev/sdb
2. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
3. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
4.
5. === START OF READ SMART DATA SECTION ===
6. General SMART Values:
7. Offline data collection status:(0x00)Offline data collection activity
8. was never started.
9. AutoOfflineDataCollection:Disabled.
10. Self–test execution status:(121)The previous self–test completed having
11. the read element of the test failed.
12. Total time to complete Offline
13. data collection:(0) seconds.
14. Offline data collection
15. capabilities:(0x73) SMART execute Offline immediate.
16. AutoOffline data collection on/off support.
17. SuspendOffline collection upon new
18. command.
19. NoOffline surface scan supported.
20. Self–test supported.
21. ConveyanceSelf–test supported.
22. SelectiveSelf–test supported.
23. SMART capabilities:(0x0003)Saves SMART data before entering
24. power–saving mode.
25. Supports SMART auto save timer.
26. Error logging capability:(0x01)Error logging supported.
27. GeneralPurposeLogging supported.
28. Shortself–test routine
29. recommended polling time:(1) minutes.
30. Extendedself–test routine
31. recommended polling time:(102) minutes.
32. Conveyanceself–test routine
33. recommended polling time:(2) minutes.
34. SCT capabilities:(0x103b) SCT Status supported.
35. SCT ErrorRecoveryControl supported.
36. SCT FeatureControl supported.
37. SCT DataTable supported.

样例：9 显示磁盘错误日志

1. root@linuxtechi:~# smartctl –l error /dev/sdb
2.
3. SampleOutput
4.
5. smartctl 6.22013–07–26 r3841 [x86_64–linux–3.13.0–32–generic](local build)
6. Copyright(C)2002–13,BruceAllen,ChristianFranke, www.smartmontools.org
7.
8. === START OF READ SMART DATA SECTION ===
9. SMART ErrorLogVersion:1
10. ATA ErrorCount:5
11. CR =CommandRegister[HEX]
12. FR =FeaturesRegister[HEX]
13. SC =SectorCountRegister[HEX]
14. SN =SectorNumberRegister[HEX]
15. CL =CylinderLowRegister[HEX]
16. CH =CylinderHighRegister[HEX]
17. DH =Device/HeadRegister[HEX]
18. DC =DeviceCommandRegister[HEX]
19. ER =Errorregister[HEX]
20. ST =Statusregister[HEX]
21. Powered_Up_Timeis measured from power on,and printed as
22. DDd+hh:mm:SS.sss where DD=days, hh=hours, mm=minutes,
23. SS=sec,and sss=millisec.It“wraps” after 49.710 days.
24.
25. Commands leading to the command that caused the error were:
26. CR FR SC SN CL CH DH DC Powered_Up_TimeCommand/Feature_Name
27. —————————————-——————–
28. 25 da 08 e7 e5 a5 4c0000:30:44.515 READ DMA EXT
29. 25 da 08 df e5 a5 4c0000:30:44.514 READ DMA EXT
30. 25 da 805f e5 a5 4c0000:30:44.502 READ DMA EXT
31. 25 da f0 5f e6 a5 4c0000:30:44.496 READ DMA EXT
32. 25 da 104f e6 a5 4c0000:30:44.383 READ DMA EXT
